⬛產品技術資訊⬛
◼Headset Microphone
Input Type: Dynamic
Input Impedance: >= 1K
Mic Limiter Threshold: 0dBu ± 3dB
Mic Limiter Range: >= 15dB

◼Program
Maximum Level before Clipping: >= 20dBu
Input Impedance: >= 5K

◼Program Mic Input
Maximum Level before Clipping : >= -35dB
Input Impedance: >= 1K

◼Headset Output
Load Impedance: >= 8
Output Impedance: <= 25
Output Limiter Threshold: +5dBu ± 3dB
Maximum Output Level before Distortion: >= 17dBu

◼Partyline Output
O Noise : < -74dBu
Output Impedance : >10K

◼Partyline Input
Crosstalk: <-60dB
Max level before Clipping: >= 12dBu
Sidetone Null Capability: > 25dB

◼Stage Announce/Balanced Line Out
Type: Balanced Output Impedance: >= 200
Load Impedance: >= 600

◼Frequency Response
Headset Mic – Partyline :200 – 18KHz ± 3dB
Headset Mic – Line Out: 200 – 18KHz ± 3dB
Program Input – Partyline: 200 – 20KHz ± 3dB
Program Input – Headset Out :200 – 18KHz ± 3dB
Partyline – Headset Out :200 – 18KHz ± 3dB

◼Max Distortion
Headset Mic – Partyline: <= 0.5%
Headset Mic – Line Out: <= 0.5%
Program Input – Partyline: <= 0.2%
Program Input – Headset Out: <= 0.2%
Partyline – Headset Out: <= 0.2%

◼Noise
Headset Mic – Partyline: < -70dBu
Program Input – Partyline: < -85dBu
Program Mic – Partyline: < -70dBu
Program Input – Headset Out: < -60dBu
Program Mic – Headset Out: < -40dBu
Partyline – Headset Out: < -50dBu

◼Max Gain
Headset Mic – Partyline: 41dB ± 2dB
Headset Mic – Announce Out: 55dB ± 3dB
Program Input – Partyline: >= -16dB
Program Mic – Partyline: 41dB ± 2dB
Program Input – Headset Out: >= 18dB
Program Mic – Headset Out: >= 70dB
Partyline – Headset Out: >= 34dB

◼Mains Power
Input Voltage Range: 100 – 240 VAC
Input Frequency Range: 50 – 60 Hz
Input Power: <= 60 VAC
Output Voltage: 30 VDC ± 0.5V

◼Output Current per Channel (Continuous): 1.2 A
Output Current per Channel
(Peak): 2 A (Do not exceed the 1.2A rating for more than 2 seconds per 1 minute period)
Short Circuit Recovery Time (1st short):<= 0.5 sec
Short Circuit Recovery Time >= 20 shorts in 20sec):<= 20 sec

◼Environmental
0 – 50°C

◼Dimensions
76 x 216 x 254 mm

◼Weight
2.3 kg

※目前無現貨 預購需等3-4周
